EX35001

Maximum Capacity	35,000 g
Readability	0.1 g
Pan Size	14.8 in x 12.2 in (377 mm x 311 mm)
Item Number:	30057065

Request a Quote ADD TO QUOTE LIST

View All Explorer™ Precision High Capacity Models

Overview
Specs
Accessories
Documents

Overview

OHAUS Explorer High Capacity balances provide unmatched functionality in a line of high-performance, high-capacity balances unlike any other on the market! This smart and intuitive balance simplifies even the most complex high-capacity laboratory measurements.

Applications

Weighing, Parts Counting, Percent Weighing, Checkweighing, Animal/Dynamic Weighing, Filling, Totalization/Statistics, Formulation, Differential Weighing, Density Determination, Peak Hold, Ingredient Costing, SQC, Statistics

Display

5.7" (145 mm) Full-color VGA graphic touchscreen display with user-controlled brightness

Operation

AC Adapter (included) or rechargeable battery (accessory sold separately)

Communication

RS232 and USB (included) or second RS232/Ethernet (accessories sold separately) . GLP/GMP data output with real-time clock.

Construction

Modular design, IP54 metal base, Die-cast top housing, stainless steel pan, up-front level indicator, integral weigh below hook, calibration lock, two touchless sensors, full housing in-use cover

Design Features

Selectable environmental filters, auto tare, user selectable span calibration points, software lockout and reset menu, user selectable communication settings and data print options, user definable project and user IDs, auto standby, up to 14 operating lan

Specifications

Maximum Capacity	35,000 g
Readability	0.1 g
Pan Size	14.8 in x 12.2 in (377 mm x 311 mm)
Internal Calibration	AutoCal™ - Automatic
Draftshield	—
Auxiliary Display Model	Available as an Accessory
Battery Life	10 Hours with Rechargeable Battery
Communication	Ethernet (Available as an Accessory);USB (Included);RS232 (Included)
Dimensions	17.44 in x 4.7 in x 14.9 in (443 mm x 120 mm x 377 mm) (LxHxW)
Display	Full-color 5.7 in VGA, touch screen
In-Use Cover	Included
Legal for Trade	Not Applicable
Linearity ±	0.2 g
Minimum Weight (USP, 0.1%, typical)	210 g
Net Weight	22 lb (10 kg)
Pan Construction	Stainless Steel
Power	Rechargeable Battery (Not Included);AC Power (Included)
Repeatability, typical	0.1 g
Stabilization Time	1 s
Tare Range	To capacity by subtraction
Units of Measurement	Singapore Tael;Ounce Troy;Pennyweight;Kilogram;Grain;Tical;Custom;Milligram;Newton;Momme;Taiwan Tael;Baht;Gram;Hong Kong Tael;Pound;Tola;Mesghal;Carat;Ounce
Working Environment	50°F – 86°F, 85%RH, non-condensing (10°C – 30°C, 85%RH, non-condensing)
