i-DT61PW
Advanced IP68/IP69K Washdown Indicator

DT61PW

Resolution 75,000
Battery Life 1600 Hours with Disposable Batteries
Outputs Not Applicable
Item Number: 30575580
Request a Quote ADD TO QUOTE LIST
View All i-DT61PW Models
Overview
The Defender 6000 Series Extreme Washdown Indicator is specifically designed for food, chemical and pharmaceutical applications including production, processing, and packaging. Defender 6000 handles the most demanding applications with a food grade polycarbonate housing equipped with 3-color check light bar, ultra-long battery life and EasyConnect™.
Applications
Weighing, Counting with APW optimization, Percent Weighing, Checkweighing, Checkcounting, Dynamic Weighing/Display Hold
Display
6-digit, 7-segment LCD display with white backlight, 45 mm high digits
Operation
6 D (LR20) Batteries (Included)
Communication
Easy access IR communication kit (available as an accessory); GLP/GMP data output with real-time clock
Construction
IP68/IP69K food grade polycarbonate housing and 316 stainless steel mounting bracket
Design Features
3-color check light bar, menu and key lock, selectable environmental and auto-print settings, stability indicator, overload/underload indicators, low battery indicator, auto shut-off, auto tare
Specifications
Resolution 75,000
Battery Life 1600 Hours with Disposable Batteries
Outputs Not Applicable
Second Scale Input Not Applicable
Protection Rating IP69k;IP68
Communication Infrared communication kit (available as an accessory)
Dimensions 10.4 in x 8.9 in x 3.3 in (265 mm x 225 mm x 85 mm) (LxHxW)
Display 7-Segment LCD with white backlight, height 45mm + 3 Color Checkweigh LED
Legal for Trade EC Type Approvable;OIML
Net Weight 6 lb (2.7 kg)
Power 6 D (LR20) batteries (included)
Tare Range To capacity by subtraction
Units of Measurement Metric Tons;Gram;Kilogram;Pound;Ounce;Pound:Ounce
Working Environment 14°F – 104°F, 80%RH, non-condensing (-10°C – 40°C, 80%RH, non-condensing)
Accessories

Item Number

30424409

Description

Cable Extension 9m D52

Request a Quote Add To Quote List Remove From Quote List

Item Number

30379716

Description

Gland M16 D52

Request a Quote Add To Quote List Remove From Quote List

Item Number

30572910

Description

IR Communication Kit

Request a Quote Add To Quote List Remove From Quote List
